ViewSonic VX2450wm-LED is a 24-inch LED-backlit monitor with 1920x1080 Full HD resolution, 5ms response time, 20,000,000:1 MEGA dynamic contrast ratio, digital and analog inputs and integrated stereo speakers. It features a piano black finish and is suitable for both home and office use. It can be mounted on a VESA compliant stand or wall mount bracket. It also has an automatic aspect ratio adjustment so when your input is a 4:3 signal, the image will not be stretched but instead it will be positioned in the middle of the screen with side bars. 3-year limited warranty, industry's best pixel performance policy and Windows 7 certification make VX2450wm-LED a great long-term investment.
The VX2450wm-LED is a 24" (23.6" viewable) LED‑backlit widescreen monitor offering Full HD 1920x1080 resolution, 5 ms response time, and a 20,000,000:1 dynamic contrast ratio. It includes analog VGA and digital DVI‑D inputs, integrated stereo speakers, and a VESA‑compliant mounting design.
This manual covers safety information, installation steps, OSD menu navigation, ergonomic adjustments, power specifications, and detailed technical specifications. It also lists package contents, warranty terms, and regulatory compliance details.
| Screen size | 24" (23.6" viewable) |
|---|---|
| Resolution | 1920x1080p |
| Contrast Ratio | 1000:1 (typ); 20,000,000:1 (dynamic) |
| Response Time | 5 ms (typ) |
| Brightness | 300 cd/m² (typ) |
| Viewing Angles | 170° horizontal, 160° vertical |
| Power Consumption | 23 W (typ) |
| Weight (with stand) | 9.9 lb (4.5 kg) |
| VESA Mount | 100 mm x 100 mm |
| LED Light Source Life | 30,000 hours (typ) |
The monitor provides an analog 15‑pin mini D‑sub VGA connector and a digital DVI‑D connector.
It comes with a three‑year limited warranty covering parts, labor, and the backlight.
The monitor operates on universal AC 100‑240 V, 50/60 Hz.
Yes, it is VESA‑compliant with a 100 mm x 100 mm mounting pattern.
