The ViewSonic® PJ559D DLP® projector features 2,700 lumens, native 1024x768 resolution, ultra-high 2000:1 contrast ratio and BrilliantColor™ technology for precise images in any lighting condition. This full-featured projector includes multiple inputs for connecting several display sources simultaneously, dual 5-watt speakers for complete multimedia presentations, vertical keystone correction for easy image adjustment, and direct off feature. Choose from whiteboard, blackboard, or greenboard mode for the best picture on your projected surface. Eco-mode extends lamp life and reduces fan noise as low as 33 dB. Protect your projector from theft and unauthorized use with the Kensington® security port and PIN lock password. High brightness, full-featured projector.
The PJ559D is a compact DLP projector offering 2,700 ANSI lumens brightness, 1024×768 XGA native resolution, and a 2,000:1 contrast ratio. It includes multiple input options, dual 5‑W speakers, vertical keystone correction, and eco‑mode that can extend lamp life to up to 4,000 hours while keeping fan noise low.
The manual covers hardware specifications, connection diagrams, optional accessories, warranty information, and regulatory compliance. It also explains how to use the OnView® on‑screen controls, customize the startup screen, and secure the unit with the Kensington lock.
| Resolution | 1024×768 XGA |
|---|---|
| Brightness | 2,700 ANSI lumens |
| Contrast Ratio | 2,000:1 |
| Lamp Power | 200 W |
| Lamp Life (Eco‑mode) | up to 4,000 hours |
| Throw Ratio | 1.97‑2.6:1 |
| Throw Distance | 47.2"‑393.6" |
| Display Size | 27.2"‑250" (diagonal) |
| Weight | 13.0 lb (5.9 kg) |
| Power Input | 100‑240 VAC, 50‑60 Hz |
The lamp lasts up to 3,500 hours in normal mode and up to 4,000 hours when eco‑mode is used.
It provides VGA (15‑pin HD D‑sub), composite video (RCA), S‑video (Mini‑Din 4‑pin), component video, and HDMI‑compatible HDMI via adapter.
The unit weighs 13.0 lb (5.9 kg).
It delivers a maximum brightness of 2,700 ANSI lumens.
