PJD5152 is a short-throw projector that features 2,600 ANSI lumens and a 3000:1 contrast ratio for large images in small spaces
The ViewSonic PJD5152 is a compact short‑throw SVGA DLP projector that delivers a 50" image from just 3 feet away. It offers 2,600 ANSI lumens brightness, a 3000:1 dynamic contrast ratio, and BrilliantColor™ technology for vivid colors. Weighing only 5.5 lb, it includes features such as 40° digital vertical keystone correction, 1.2× optical zoom, and an eco‑mode lamp life of up to 6,000 hours.
This manual covers safety information, installation steps, control functions, and detailed technical specifications. It also lists optional accessories, connectivity options, operating conditions, and warranty details to help users set up and maintain the projector effectively.
| Resolution | 800x400 (Native) SVGA |
|---|---|
| Brightness | 2600 Lumens |
| Contrast Ratio | 2000:1 (typ), 3000:1 (dynamic) |
| Lamp Life | 4000 h (Normal) / 6000 h (Eco‑mode) |
| Throw Ratio | 0.9:1‑1.08:1 |
| Weight | 5.5 lb (2.5 kg) |
| Power Consumption | 280 W (typical) |
| Operating Temperature | 32 °F‑104 °F (0 °C‑40 °C) |
| Dimensions | 10.4" × 3.8" × 8.86" (264 mm × 96.4 mm × 225 mm) |
The lamp lasts up to 4,000 hours in normal mode and up to 6,000 hours in Eco‑mode.
A 50‑inch image can be projected from a distance of about 3 feet (0.69 m).
The projector weighs 5.5 lb (2.5 kg).
