The 74AHC/AHCT00 are high-speed Si-gate CMOS devices and are pin compatible with low power Schottky TTL (LSTTL). They are specified in compliance with JEDEC standard No. 7A. The 74AHC/AHCT00 provides the 2-input NAND function.
The Philips 74AHC00 and 74AHCT00 are high‑speed Si‑gate CMOS quad 2‑input NAND gates, pin‑compatible with low‑power Schottky TTL. They feature ESD protection, Schmitt‑trigger inputs and operate over a wide temperature range.
The document provides electrical characteristics, recommended operating conditions, pin configurations, ordering information and package options for both the AHC (CMOS‑level inputs) and AHCT (TTL‑level inputs) variants.
| Supply voltage (Vcc) | 4.5 V – 5.5 V |
|---|---|
| Operating temperature range | -40 °C to +125 °C |
| Propagation delay (typical) | 3.2 ns |
| Input capacitance | 15 pF |
| ESD protection (HBM) | exceeds 2000 V |
The devices operate with a DC supply voltage (Vcc) of 4.5 V to 5.5 V.
Typical propagation delay is about 3.2 ns at the specified test conditions.
The NAND gate includes HBM ESD protection that exceeds 2000 V.
It is specified for operation from –40 °C up to +125 °C.
