The Olympus 35RC is a full‑frame 35 mm film camera featuring a double‑image coupled rangefinder, automatic and manual exposure modes, and an easy‑loading system. It includes a self‑timer, accessory shoe, and a built‑in flash synchronization contact.
The manual covers battery installation (1.35 V mercury PX‑625 or equivalent), film loading, shutter speed selection, focusing, and camera care. Detailed specifications such as lens optics, shutter speed range, ASA film speed range, and dimensions are provided.
| Lens | E. Zuiko 42 mm F2.8, 5 elements in 4 groups |
|---|---|
| Shutter Speed Range | B, 1/15 – 1/500 |
| Flash Synchronization | xX contact |
| ASA Film Speed Range | ASA 25 – 800 (DIN 15 – 30) |
| Size & Weight | 109 × 70 × 50 mm, 410 g |
Place a coin in the battery compartment, rotate counter‑clockwise to open, insert a clean‑wiped mercury battery with the (+) end outward, then close the lid.
The camera uses 35 mm roll film (24 × 36 mm full frame).
Set the red mark “A” to the central index, point the camera at a bright object, and press the shutter release; if the shutter fires, the battery is correctly installed.
