This document describes the features of the Nikon Speedlight SB-10, including its lightweight and compact design, as well as its advanced circuitry. The flash utilizes a series-circuit configuration with silicon-controlled rectifiers to retain unused charge in the capacitor for ultra-rapid recycling. In automatic operation, the flash has a recycling time of less than 1 second at a distance of 1 meter and an aperture of f/4 (ASA 100 film speed). The flash also offers multiple flash operation and manual exposure override.
This manual provides step‑by‑step instructions for setting up the Nikon SB‑10 Speedlight, including battery installation, mounting the unit on compatible Nikon cameras, and using the built‑in ready‑light contact. It also covers flash synchronization methods, automatic and manual exposure operation, and how to use the exposure calculator and reflector.
The specifications section lists the guide number, coverage angles, power source, dimensions, and weight. Accessories such as the wide‑flash adapter and battery holder are described, and a camera/speedlight combination chart helps users match the SB‑10 with various Nikon bodies. This manual is written in Chinese.
| Guide number | 25 meters (ASA 100, manual) |
|---|---|
| Angle of coverage | 56° horizontal, 40° vertical |
| Power source | Four 1.5 V AA‑type batteries |
| Dimensions | 110 × 79 × 37 mm (excluding mounting foot) |
| Weight | Approx. 270 g (without batteries) |
| Ready‑light | Provided, also serves as open‑flash button |
Depress the knurled surfaces on the top and bottom to pop out the battery holder, insert four AA batteries with correct polarity, and click the holder back into place.
The guide number is 25 meters when using ASA 100 film in manual mode.
