maxim 9111/9113 is a single/dual lvds receiver that supports 500mbps switching rates, complies with tia/eia-644 standard, and has low 300ps(max) pulse skew, which can be used for high-resolution imaging applications
The MAX9111 (single) and MAX9113 (dual) are low‑voltage differential signaling (LVDS) receivers designed for high‑speed applications such as laser printers and digital copiers. They operate from a single +3.3 V supply, provide ultra‑low 300 ps max pulse skew, and support data rates up to 500 Mbps.
The devices are offered in compact 8‑pin SOT23 and SO packages, feature a fail‑safe output that goes high when inputs are undriven, and include ESD protection up to +11 kV (Human Body Model). Recommended PCB layout practices, termination, and cabling guidelines are provided to ensure optimal performance.
| Pulse Skew | 300 ps (max) |
|---|---|
| Power Dissipation | 29 mW at 3.3 V |
| Maximum Data Rate | 500 Mbps |
| Supply Voltage | Single +3.3 V |
| Fail‑Safe Output | Output high when inputs undriven |
| LVDS Input Voltage Range | 0 V to 2.4 V |
| Package Options | 8‑pin SOT23 and SO |
The devices support a guaranteed data rate of up to 500 Mbps.
Typical power dissipation is 29 mW when powered at 3.3 V.
The maximum pulse skew is specified as 300 ps.
Both parts operate from a single +3.3 V supply.
