The MAX3984 is a single-channel, preemphasis driver with input equalization that operates from 1Gbps to 10.3Gbps. It provides compensation for copper links, such as 8.5Gbps Fibre Channel and 10.3Gbps Ethernet, allowing spans of up to 10m with 24 AWG cable.
The MAX3984 combines a receiver, a driver, and an LOS detector in a lead‑free 3 mm × 3 mm 16‑pin thin QFN package. It provides four selectable pre‑emphasis levels, selectable input equalization for up to 10 in of FR‑4 at 10 Gbps, and SFP‑compatible loss‑of‑signal detection with TX_DISABLE control. The device operates from 0 °C to +85 °C and supports data rates up to 10.3 Gbps for Ethernet and Fibre Channel applications.
Typical applications include high‑speed back‑plane links, copper cable assemblies, and active optical modules where signal integrity over long copper runs is required. The datasheet includes detailed electrical specifications, pin descriptions, package drawings, and test‑setup diagrams for both transmit and receive paths.
| Supply Voltage Range (VCC) | -0.5 V to +4.1 V |
|---|---|
| Continuous Output Current Range (OUT+, OUT‑) | -25 mA to +25 mA |
| Operating Ambient Temperature | 0 °C to +85 °C |
| Maximum Data Rate | 10.3 Gbps |
| Selectable Output Swing | 1000 mVP‑P (low) or 1200 mVP‑P (high) |
| Package Type | Thin QFN‑EP 3 mm × 3 mm, 16‑pin |
The device operates with a supply voltage from –0.5 V to +4.1 V.
Four selectable pre‑emphasis levels are provided.
It supports data rates up to 10.3 Gbps.
It is offered in a 3 mm × 3 mm thin QFN‑EP package with 16 pins.
