This datasheet provides a detailed introduction to the features and characteristics of MAX9210/MAX9214/MAX9220/MAX9222 products, including interfaces, working voltage, and working temperature range.
The MAX9210, MAX9214, MAX9220 and MAX9222 are 21‑bit LVDS deserializers that convert three LVDS serial data inputs into single‑ended LVC‑MOS/LVTTL outputs. They feature programmable DC‑balance, allowing AC‑coupled isolation between serializer and deserializer, and support both rising‑edge and falling‑edge output strobes.
These devices are supplied in a 48‑lead TSSOP package, operate over –40 °C to +85 °C, and are suitable for automotive navigation, DVD entertainment, digital copiers, and laser printers. The datasheet provides electrical characteristics, pin descriptions, programming tables, and package dimensions.
| Operating Temperature Range | -40 °C to +85 °C |
|---|---|
| Package Type | 48‑lead TSSOP |
| Maximum Data Throughput | 1.785 Gbps |
| Supply Voltage Options | 1.8 V, 2.5 V, 3.3 V, 5 V logic levels |
| DC‑Balance Programmable | Yes |
The devices can achieve up to 1.785 Gbps throughput.
They operate from –40 °C to +85 °C.
They are offered in a 48‑lead TSSOP package.
The MAX9220 and MAX9222 provide falling‑edge output strobes.
