ADC108S052 is a low-power, eight-channel CMOS 10-bit analog-to-digital converter specified for conversion throughput rates of 200 kSPS to 500 kSPS.
The ADC108S052 is an eight‑channel, low‑power CMOS 10‑bit analog‑to‑digital converter supporting conversion rates from 200 kSPS to 500 kSPS. It operates from independent analog and digital supplies (+2.7 V to +5.25 V) and is packaged in a 16‑lead TSSOP.
The document provides detailed pin descriptions, absolute maximum ratings, electrical characteristics, timing specifications, layout recommendations, and physical dimensions, along with ordering information and typical performance graphs.
| Resolution | 10 Bits |
|---|---|
| Conversion Rate | 200 kSPS to 500 kSPS |
| Package | 16‑lead TSSOP |
| Operating Temperature Range | -40 °C to +105 °C |
The ADC108S052 provides a 10‑bit resolution with no missing codes.
It supports conversion rates from 200 kSPS up to 500 kSPS.
It is offered in a 16‑lead TSSOP package.
