The PCS-TL33 is a network-ready visual communication system that allows you to instantly communicate over IP networks. This unit is ideal for use on individual desktops and can even be used in small meeting spaces or kiosks as required.
The PCS‑TL33 is an all‑in‑one visual communication system that combines a 17.1‑inch WXGA LCD, built‑in high‑quality camera, speakers, microphone and optional data solution module. It offers one‑click dialing, KIOSK mode, multiple display layouts and network‑ready video/audio codecs for easy videoconferencing from a desktop or small meeting space.
The manual covers hardware installation, network configuration, optional accessories, security features such as 128‑bit encryption, and quality‑of‑service functions like Adaptive Rate Control and real‑time ARQ. It also lists technical specifications, accessory options, and troubleshooting guidance.
| Display size | 17.1‑inch Widescreen LCD |
|---|---|
| Resolution | 1280 × 768 (WXGA) |
| Camera sensor | 1/3.8‑type CMOS |
| Audio codec | MPEG‑4 AAC (mono) 14 kHz at 64/96 kb/s |
| Network bitrate | Up to 2048 kb/s in H.323 (incl. audio) |
| Power input | AC 100‑240 V, 50/60 Hz |
| Weight | Approx. 17 lb (8 kg) |
| Dimensions (without stand) | 16 3/4 × 14 ½ × 3 /4 in (424 × 376 × 95.5 mm) |
Up to 30 contacts can be flagged for one‑click dialing from a maximum of 500 registered contacts.
