The N-5030 is a HEXSEAL actuator designed for harsh environments, offering high temperature and pressure resistance. It is constructed from silicone rubber and features a brass, nickel‑plated mounting nut.
Key specifications include a temperature range of -94°F to +400°F, pressure capability up to 1500 psi external, a minimum operational life of 50,000 actuations, and certifications such as UL‑listed to UL Std. 50 types 1‑13 and CSA compliance.
| Material | Silicone rubber, 22‑R‑765 Class III, GR 50 |
|---|---|
| Mounting Nut | Brass, nickel‑plated |
| Temperature Range | -94°F to +400°F |
| Pressure Range | ≥15 psi internal, 1500 psi external |
| Operational Life | 50,000 actuations (minimum) |
| Shelf Life | More than 25 years |
| Resistance | Salt spray, sun‑fight, ozone, weather, fungus, most acids and lubricating oils |
| Military Approvals | OPL‑approved to IL‑E‑ |
| Agency Recognition | UL‑listed to UL Std. 50 types 1‑13, meets CSA standards |
The N-5030 operates from -94°F up to +400°F.
It is rated for a minimum of 50,000 actuations.
It is UL‑listed to UL Std. 50 types 1‑13 and meets CSA standards.
