This manual introduces the use of Yamaha DGX-230/YPG-235 electronic piano.
This manual provides safety warnings, power‑supply requirements, battery information, and proper handling instructions for the Yamaha DGX‑230/YPG‑235 digital keyboard. It also explains how to set up the instrument, connect accessories, and back up your data.
Additional sections cover the included accessories, special features such as graded soft‑touch keys and auto‑accompaniment styles, and contact information for Yamaha service centers worldwide.
| Instrument type | Digital Keyboard |
|---|---|
| Model name | DGX-230/YPG-235 |
| Recommended AC adapter | PA-150 (or equivalent recommended by Yamaha) |
| Battery type | Small non‑rechargeable battery (soldered) and optional household batteries |
Use the Yamaha‑specified PA‑150 adapter or an equivalent model recommended by Yamaha; using a different adapter can cause damage.
Extension cords are not recommended; if you must use one, it should be no longer than 25 ft and at least 18 AWG.
Dispose of used batteries according to local, state, and federal regulations; do not incinerate or mix battery types.
The name plate on the bottom of the product displays the model number, serial number, and power requirements.
