ADP130 is a CMOS linear regulator with a maximum output current of 350 mA, a wide input voltage range, and low quiescent current. It is suitable for portable battery-powered devices such as mobile phones, digital cameras, and audio devices.
The ADP130 linear regulator provides a low quiescent current and very low dropout voltage, making it ideal for portable, battery‑powered equipment such as mobile phones and digital cameras. It operates from an input voltage as low as 1.2 V and can supply up to 350 mA of output current, with a typical dropout of 17 mV at 100 mA load.
The device includes built‑in current‑limit and thermal‑overload protection, logic‑controlled enable, and is offered in a compact 5‑lead TSOT package. Recommended external capacitors are small 1 µF ceramic types, allowing a minimal board footprint while maintaining stable operation.
| Maximum output current | 350 mA |
|---|---|
| Dropout voltage (100 mA load) | 17 mV |
| Quiescent current (no load) | 25 µA |
| Shutdown current | <1 pA |
| PSRR (10 kHz) | 70 dB |
The ADP130 can deliver up to 350 mA of output current.
It has a dropout voltage of 17 mV when delivering 100 mA.
The quiescent current is about 25 µA with no load.
It is offered in a tiny 5‑lead TSOT package.
