UT2152C is a digital storage oscilloscope from Uni-Trend. It has a bandwidth of 150MHz, a rise time of 2.3ns, a sample range of 500MS/s to 1GS/s, a vertical sensitivity of 2mV to 5V/div, a record length of 1M (max), a real-time sampling rate of 500MS/s to 1GS/s, equivalent to 25GS/s scan time base, 2ns to 50s/div trigger type, edge, pulse, video and alternate automatic waveform measurements 28 ports, standard: USB device, USB host and RS-232C, optional: LAN mathematics add, subtract, divide, reverse and FFT applications College education, R&D, electronic product assembly line, industrial control, etc.
The UT2152C is a digital storage oscilloscope aimed at college education, R&D, electronic product assembly lines, and industrial control applications. It features a 64k full‑colour LCD with a 320 × 240 pixel resolution and offers standard ports including USB Device, USB Host, RS‑232C and optional LAN.
Key specifications include a 150 MHz bandwidth, 2.3 ns rise time, up to 1 GS/s real‑time sampling (equivalent 25 GS/s), and a maximum record length of 1 M points. The unit is powered by 100‑240 VAC, weighs 2.5 kg, and ships with two interchangeable probes, a power cord, and an English manual.
| Bandwidth | 150 MHz |
|---|---|
| Rise Time | 2.3 ns |
| Sample Rate | 1 GS/s (real‑time), 25 GS/s (equivalent) |
| Record Length (Max) | 1 M points |
| Vertical Sensitivity | 2 mV ~ 5 V/div |
| Display | 64k full‑colour LCD, 320 × 240 pixels |
| Power Input | 100‑240 VAC RMS, 45‑440 Hz, CAT II |
| LCD Size | Diagonal 145 mm (5.7 inches) |
| Product Net Weight | 2.5 kg (excluding packaging) |
| Product Size | 320 mm × 150 mm × 130 mm (W × H × D) |
The UT2152C provides a bandwidth of 150 MHz.
It includes standard USB Device, USB Host, RS‑232C ports, with an optional LAN port.
The oscilloscope can record up to 1 M points.
The package includes two interchangeable probes (1×, 10×), a power cord, and an English manual.
