The LM6181 is a 100 MHz current feedback amplifier with a slew rate of 2000V/µs. It is ideal for data acquisition, high speed ATE, and precision pulse amplifier applications.
The LM6181 current‑feedback amplifier offers a combination of high bandwidth, fast slew rate, and strong output drive. It can handle up to 100 pF capacitive loads and drive a 10 V signal into 100 Ω, making it suitable for video, data‑acquisition, and high‑speed pulse applications.
The document provides absolute maximum ratings, electrical characteristics for both DC and AC operation, typical performance curves, and mechanical dimensions for DIP and SO packages. It also includes application examples, life‑support usage restrictions, and compliance information.
| Slew Rate | 2000 V/µs |
|---|---|
| Closed‑Loop Bandwidth (gain = -1) | 100 MHz |
| Output Drive | +10 V into 100 Ω |
| Supply Voltage Range | 7 V to 32 V |
The absolute maximum supply voltage is +18 V.
Soldering the dual‑in‑line package for 10 seconds at 260 °C is recommended.
No, National Semiconductor does not authorize the LM6181 for use as a critical component in life‑support devices.
