TLC2652 series is TI's high-precision chopper-stabilized operational amplifier, using TI's high-precision LinCMOS process, using unique chopper-stabilized circuitry, making the performance of this series of operational amplifiers comparable to or better than existing similar devices.
The TLC2652, TLC2652A and TLC2652Y are high‑precision chopper‑stabilized operational amplifiers built with Texas Instruments' Advanced LinCMOS process. They offer extremely low offset voltage, low input bias current, and high common‑mode rejection, making them suitable for low‑level signal processing such as strain‑gauge and thermocouple interfaces.
The devices are offered in 8‑pin, 14‑pin, 20‑pin and FK packages, support single‑supply operation down to +1.9 V, and include built‑in ESD protection. Absolute maximum ratings, recommended operating conditions, and mechanical dimensions are detailed in the datasheet, along with an important notice on product availability and warranty.
| Supply voltage (Vpp+) | +1.9 V to +8 V |
|---|---|
| Common‑mode input range | Includes the negative rail |
The TLC2652 series can operate with a supply voltage (Vpp+) from +1.9 V up to +8 V.
The device is offered in 8‑pin, 14‑pin, 20‑pin, and FK (chip) packages.
