KSC-SW10 is a powered enclosed subwoofer from Panasonic with a 200W output power and a 10-inch woofer.
This manual begins with important safety instructions and detailed wiring diagrams for connecting the KSC‑SW10 subwoofer to a vehicle’s audio system. It covers the required automotive‑grade wires, grounding procedures, fuse replacement, and recommended mounting locations to ensure safe and reliable operation.
The second part explains how to operate the subwoofer using the remote control, including the phase switch, frequency and level knobs, and how to adjust bass response. It also lists the technical specifications, provides a troubleshooting guide for common issues, and includes a parts list for installation.
| Type | Powered Enclosed Subwoofer |
|---|---|
| Maximum output | 150 W |
| Frequency response | 35 – 120 Hz |
| Signal‑to‑noise ratio | 85 dB |
| Cut‑off frequency | 50 – 120 Hz |
| Phase settings | 0°, 180° |
| Input sensitivity / Impedance | 50 mV, 15 Ω |
| Weight | 3.4 kg |
| Fuse capacity | 10 A |
Turn the LEVEL control knob on the remote control to increase or decrease the low‑frequency output to the desired level.
A 10 A fuse must be used as specified in the manual.
