This user guide introduces the features and functions of the Origen M10 HTPC enclosure.
This guide introduces the Origen M10 HTPC enclosure, describing its aluminum chassis, front panel controls, and accessory options such as the external adapter and remote control. Detailed diagrams show the layout of the case, VFD/IR module, and internal PCB connections.
Installation sections cover opening the case, mounting a 2.5‑inch HDD/SSD, installing an optical drive, fitting a Mini‑ITX motherboard, and configuring the VF310 VFD/IR module. The manual also includes adapter specifications and software setup for the VF310 controller.
| Supported drive size | 2.5 inch HDD or SSD |
|---|---|
| Maximum CPU cooler height | 80 mm |
| Supported motherboard form factor | Mini‑ITX |
| Case fixing screws | 4 |
| External adapter model | FSP150‑AHAN1 |
| Adapter dimensions | 72 mm (W) × 171 mm (H) × 40 mm (D) |
Four fixing screws need to be removed to open the case.
The enclosure supports 2.5‑inch HDDs or SSDs.
The maximum CPU cooler height is 80 mm.
A Mini‑ITX motherboard can be installed.
