Hisense HK800 series POS is a commercial equipment that adopts Intel® technical design with low power consumption and eco-friendly characteristics. It has flexible and reliable touch technology, making the operation more humanized and easier. The globally adopted vertical AIO status makes it stable and occupies less space. The screen is the integrating center, and the screen angle of the HD screen can be adjusted casually according to your needs. The modular design allows for tool-free disassembly, making maintenance and system updates easier. The POS can connect various peripherals with its enriched and alterable interface technology.
This manual covers the complete setup of the Hisense HK800 POS system, including unpacking, component identification, and assembly steps. It guides technical personnel through safe installation, power requirements, and environmental conditions.
Key sections detail operating system and driver installation, peripheral connections such as printers, cash drawers, and customer displays, as well as system configuration and self‑check procedures to verify proper operation.
| Input Voltage | AC220V 50Hz |
|---|---|
| Current | 3 A |
| Working Temperature | 5 ℃ – 40 ℃ |
| Working Humidity | 20 % – 90 % |
| Dimensions (W×D×H) | 368 mm × 380 mm × 400 mm |
| Customer Display Voltage | 12 V |
| Earthing Resistance Requirement | < 0.1 Ω |
The HK800 series supports Windows 98, Windows 2000, Windows XP, and Windows Vista, but not DOS or Windows 95.
The external power supply must have an earthing resistance smaller than 0.1 Ω to avoid cabinet electrification.
Run the setup program located in the \TouchScreen\ETT\vistaxp2kme98-ett (or appropriate folder) and follow the on‑screen prompts.
COM3 should be set to 12 V, matching the working voltage of the customer display.
