Hisense Scanner SC188AT is Hisense brand high performance handheld scanner, it has outstanding value, superior motion tolerance, multiline mastering scan pattern and engineered for reliability. The scanner can help improve productivity, higher quality construction can reduce maintenance costs and reduce downtime. Even novice users can speed up the checkout process and increase customer satisfaction in retail, warehouse and pharmacies environments.
The SC188AT is a handheld barcode scanner aimed at checkout counters, pharmacies, hospitals and warehouses. It features a visible laser diode (630‑650 nm) with EN60825‑1 class‑1 safety rating, fast 100 cycle/second decode speed, and a robust ABS+PC case that survives drops from up to 4 m.
Technical specifications include a 460° scan angle (left‑right), +65° front‑back, and 442° turn capability, support for a wide range of symbologies (UPC‑A/E, EAN‑13/8, ISBN/ISSN, Code 39/32, MSI/Plessey, UK/Plessey, UCC/EAN‑128, GS1 DataBar), and interfaces such as PS/2, RS‑232 and USB. The device operates from a 5 V DC supply, draws up to 100 mA transient current, and works in temperatures from 0 °C to 45 °C (storage –40 °C to 60 °C).
| Voltage | DC5 V ±0.25 V |
|---|---|
| Power (operation) | 425 mW |
| Power (transient max) | 500 mW |
| Current (operation) | 85 mA |
| Current (transient max) | 100 mA |
| Light source | Visible laser diode, 630‑650 nm |
| Laser safety grade | EN60825‑1, Class 1 |
| Decode speed | 100 cycles/second |
| Scan angle | 460°, +65°, 442° (left‑right, front‑back, turn) |
| Minimum barcode width | 0.08 mm (3 mil) |
| Supported symbologies | UPC‑A, UPC‑E, EAN‑13, EAN‑8, ISBN/ISSN, Code 39, Code 32, MSI/Plessey, UK/Plessey, UCC/EAN‑128, GS1 DataBar |
| Interface | PS2 / RS‑232 / USB |
| Dimensions (D×L×H) | 9.5 cm × 6.7 cm × 15.4 cm |
| Weight | 148 g (no cable) |
| Operating temperature | 0 °C ~ 45 °C |
| Storage temperature | -40 °C ~ 60 °C |
| Humidity range | 5 % ~ 90 % |
| Anti‑shock rating | Survives 4 m drops |
It provides a 460° left‑right scan, +65° front‑back, and 442° turn angle.
It decodes UPC‑A, UPC‑E, EAN‑13, EAN‑8, ISBN/ISSN, Code 39, Code 32, MSI/Plessey, UK/Plessey, UCC/EAN‑128 and GS1 DataBar.
The device offers PS2, RS‑232 and USB interfaces.
It operates from 0 °C to 45 °C.
