The LZ4-00NW10 is a high luminous efficacy neutral white LED emitter with a small footprint, low thermal resistance, high luminous flux density, spatial color uniformity, and long lumen maintenance.
The LZ4-00NW10 is a 10 W neutral‑white LED emitter with an ultra‑small 7 mm × 7 mm × 4.3 mm footprint. It offers high luminous efficacy, low thermal resistance, and excellent lumen maintenance for demanding lighting applications.
The datasheet provides detailed optical, electrical, mechanical, and reliability specifications, along with recommended solder pad layouts, reflow profiles, and tape‑and‑reel packaging information for designers and manufacturers.
| Allowable Reflow Cycles | 6 |
|---|---|
| Thermal Resistance (J‑C) | 27 °C/W |
| Moisture Sensitivity Level | JEDEC Level 2 |
It complies with JEDEC Level 2 moisture sensitivity.
