The µA741 is a general-purpose operational amplifier featuring short-circuit protection, offset-voltage null capability, large common-mode and differential voltage ranges, no frequency compensation required, low power consumption, and no latch-up.
The A741 is a general‑purpose operational amplifier featuring offset‑voltage null capability, short‑circuit protection, and a wide common‑mode input range. It is offered in multiple packages (D, J, JG, P, PW, U, FK) with temperature ratings from –55 °C to 125 °C.
The document provides absolute maximum ratings, electrical characteristics, mechanical dimensions, and application notes such as the input offset voltage null circuit. It also includes a notice on product warranties and usage restrictions.
| Supply voltage (Vcc) | ±15 V |
|---|---|
| Input offset voltage (typical) | 6 mV |
| Input bias current (typical) | 80 nA |
| Common‑mode input voltage range | +12 to +13 V |
| Maximum output short‑circuit duration | Unlimited |
The A741 operates with a supply voltage of ±15 V.
Typical input offset voltage is about 6 mV, with a range from 0 to 8 mV.
Yes, the output can be shorted to ground indefinitely; the duration is unlimited.
