This is a PCI diagnostic tool that can be used by network administrators on-site or out in the field to locally diagnose and perform functions on your system.
The Reviver PRP-01 is a fully featured PCI Diagnostic Tool designed for on‑site or remote network administration. It can display the execution of more than 100 tests on power‑up, show internal ambient temperature, and record all test results to an internal database for later analysis.
Key features include vendor‑independent and OS‑independent operation, USB V2.0 connectivity, on‑board CPU and firmware connectors, LED status indicators, and compliance with RoHS and CE standards. The device operates within a temperature range of 0 °C to 55 °C and is built to withstand storage conditions from –20 °C to +70 °C.
| PCI Standard | v2.2 32‑bit, 33 MHz, 5 V bus |
|---|---|
| Operating Temperature | 0 °C – 55 °C (32 °F – 131 °F) |
| Storage Temperature | -20 °C – +70 °C (-4 °F – 158 °F) |
| Humidity Range | 10% – 90% non‑condensing |
| Dimensions | 135 cm × 85 cm |
| USB Interface | USB V2.0 |
| LED Support | Yes |
| CPU | On‑board |
| BIOS Compatibility | All BIOSs supported |
It operates from 0 °C up to 55 °C.
Yes, it supports all BIOSs.
The device includes a USB V2.0 port, an ATX on‑board connector, and an on‑board firmware connector.
Yes, it is RoHS compliant and carries the CE mark.
