LMV651/LMV652/LMV654 are National's high performance, low power operational amplifier ICs implemented with National's advanced VIP50 process. This family of parts features 12 MHz of bandwidth while consuming only 116 μA of current, which is an exceptional bandwidth to power ratio in this op amp class.
National Semiconductor’s LMV651/LMV652/LMV654 family provides high‑performance, low‑power operational amplifiers for general‑purpose amplification in low‑voltage applications. They are offered in ultra‑tiny 5‑Pin SC70/SOT‑23 (LMV651), 8‑Pin MSOP (LMV652) and 14‑Pin TSSOP (LMV654) packages and operate from 2.7 V to 5.5 V, making them suitable for automotive, sensor and portable equipment.
Key electrical characteristics include a unity‑gain bandwidth of 12 MHz, input offset voltage of 1.5 mV, PSRR of 95 dB, CMRR of 100 dB, and total harmonic distortion of 0.003 % at 1 kHz into a 2 kΩ load. Typical supply currents are 116 pA (LMV651), 118 pA (LMV652) and 122 pA (LMV654). The datasheet also provides detailed performance curves, recommended land patterns, and ordering information.
| Bandwidth | 12 MHz |
|---|---|
| Input Offset Voltage | 1.5 mV (max) |
| PSRR | 95 dB |
The maximum input offset voltage is 1.5 mV.
The unity‑gain bandwidth is 12 MHz.
Typical supply current for LMV652 is 118 pA per amplifier.
