This document provides a datasheet for a font design product manufactured by Forge Europa Limited. The product features high segment intensity, extra wide viewing angle, lightweight design, and is available in red, yellow, green, and blue colors.
The FEM-790XX00GW range offers 7.9" (200 mm) interlocking 7‑segment displays with optional decimal point. Available in red, yellow, green and blue segment colours, the modules feature high segment intensity, extra‑wide viewing angle and lightweight construction.
Key electrical characteristics include a pulse forward current of 400 mA (0.1 duty cycle @1 kHz), DC forward current of 100 mA, reverse voltage of 20 V, operating temperature from –25 °C to +80 °C, and storage temperature from –30 °C to +85 °C. The package provides a 125‑digit width layout with four 4.5 mm holes for mounting.
| Display size | 7.9" (200 mm) |
|---|---|
| Segment intensity | High |
| Viewing angle | Extra wide |
