Fatal1ty Z77 Professional-M Series is a motherboard designed for gaming enthusiasts by ASUS. It supports the latest Intel 4th Generation Core processors and features ASUS's unique 5X Protection II technology for a more stable and reliable gaming experience.
This guide introduces the ASRock Z77 Professional-M Series motherboard, a Micro ATX board featuring Intel Z77 chipset, 8+3 power phase design and support for 2nd‑ and 3rd‑generation Intel Core i7/i5/i3 CPUs. It lists the package contents, provides a detailed layout of connectors, slots and headers, and explains key features such as premium gold capacitors and multi‑streaming audio.
The document also contains a step‑by‑step installation procedure, BIOS recommendations (AHCI mode for Windows 7/ Vista), and troubleshooting notes. Technical specifications for CPU, memory, expansion slots, storage interfaces and I/O ports are summarized for quick reference.
| Form Factor | Micro ATX 9.6" x 9.6" (24.4 cm x 24.4 cm) |
|---|---|
| CPU Socket | LGA1155, supports 2nd‑ and 3rd‑generation Intel Core i7/i5/i3 |
| Chipset | Intel® Z77 |
| Supported Memory Speeds | DDR3 2800+(OC)/2400/2133/1866/1600/1333/1066 |
| USB Ports | 4 x USB 3.0, 6 x USB 2.0, 1 x USB Type‑C (Mouse Port) |
Set the BIOS option in Storage Configuration to AHCI mode for better performance on Windows 7/7 64‑bit/Vista.
