Fatal1ty Z77 Performance Series is a Fatal1ty series Z77 motherboard, which is mainly for e-sports games. It adopts Intel Z77 chipset, 8 phase power supply, supports Intel Haswell processor, supports overclocking, and is equipped with Killer E2200 network card, Bluetooth 4.0, and supports 128GB mSATA solid state hard disk. It has the characteristics of e-sports gaming motherboards and is suitable for gamers to buy.
This guide provides an overview of the ASRock Z77 Performance Series motherboard, including its ATX form factor, CPU socket, chipset, memory support, and expansion slots. It also details the I/O panel, audio multi‑streaming options, and required BIOS settings.
The document includes step‑by‑step installation instructions, Windows 7 hot‑fix guidance, and troubleshooting tips to help users assemble and configure the board for optimal performance.
| Form Factor | ATX (12.0‑in x 9.6‑in, 30.5 cm x 24.4 cm) |
|---|---|
| CPU Socket | LGA1155, supports 2nd/3rd‑Gen Intel Core i7/i5/i3 |
| Chipset | Intel® Z77 |
| Memory Slots | 4 DDR3 DIMM slots, up to 32 GB |
| PCI Express Slots | 1 × PCIe 3.0 x16, 1 × PCIe 2.0 x16 (x4), 1 × PCIe 2.0 x1, 2 × PCI |
Set the BIOS option in Storage Configuration to AHCI mode for best performance.
The board provides four DDR3 DIMM slots.
It uses the standard ATX form factor measuring 12.0 in × 9.6 in.
Install Microsoft hot‑fix KB2505454 after installing Windows 7 64‑bit.
