1 Fatal1ty P67 Professional Series Motherboard English
This manual introduces the Fatal1ty P67 Professional Series ATX motherboard, describing its layout, I/O panel, and supported components. It includes a quick‑start guide, detailed installation instructions, and guidance for BIOS setup and operating‑system installation.
The document also lists the technical specifications, such as CPU socket type, memory capacity, expansion slots, audio and networking features, and provides troubleshooting tips like enabling multi‑streaming audio and configuring SATA modes for Windows.
| Form factor | ATX 12.0‑in x 9.6‑in |
|---|---|
| CPU socket | 1155‑Pin LGA1155 |
| Chipset | Intel P67 |
| Memory slots | 4 x DDR3 DIMM slots |
| Maximum memory | 32 GB |
| PCI‑Express slots | 3 x PCIe 2.0 x16, 2 x PCIe 2.0 x1, 2 x PCI |
| Audio codec | Realtek ALC892 |
| LAN ports | 2 x Gigabit Ethernet (10/100/1000 Mb/s) |
| SATA3 connectors | 6 x 6.0 Gb/s SATA3 ports |
| USB 3.0 ports | 4 x rear USB 3.0 ports |
| BIOS size | 64 Mb AMI BIOS |
The board provides four DDR3 DIMM slots.
The motherboard measures 12.0 inches by 9.6 inches (30.5 cm × 24.4 cm).
