The Thermaloy series offers extruded tee‑slot mounting for 80 mm power modules and solid‑state relays, with the option to mount stud devices. The top surface is machined before black anodising and can accept covers on three sides.
Performance data for Type D heatsinks are presented, including thermal resistance versus length at various local air speeds. Graphs show power handling up to 450 W and corresponding temperature rise (°C/W) when the heatsink operates 80 °C above ambient.
| Mounting type | Extruded tee‑slots for 80 mm modules |
|---|
It features extruded tee‑slots for mounting 80 mm power modules and solid‑state relays, and also allows stud devices to be mounted.
