6398BG is a high power extruded Heatsink with large radial fins and straight pins from Aavid Thermalloy.

Aavid 6398BG Thermal Interface Material Data Sheet - cover page

Brand: AAVID
Category: Other
Document type: Datasheet
Language: English
Pages: 2
File format: PDF
File size: 44 KB
Published: 12 April, 2012
Updated: 30 September, 2023
MD5 checksum: 1A5CE4ED28950C78BEDB93811413C0CC
PDF: Aavid 6398BG Thermal Interface Material Data Sheet PDF

About this manual

The 6398BG is a board‑mounting, high‑power extruded heatsink featuring large radial fins and straight pins, finished in black anodize. It is designed for use with TO‑220 packages and offers a standard part number for easy ordering.

The datasheet includes mechanical outline dimensions, thermal resistance curves based on a 75 °C temperature rise in natural convection, and air‑velocity performance data. Technical support is available via phone or email, and custom solutions can be requested from Aavid.

What's inside

Standard Products
Mechanical Outline Drawing
Thermal Curves
Air Velocity and Thermal Resistance
Product Information
Technical Support

Specifications

Part Number	6398BG
Finish	Black Anodize
Mounting Type	Board Mounting
Package Compatibility	TO‑220

Frequently asked questions

What is the part number of this Aavid thermal product?

The part number is 6398BG.

What finish does the 6398BG heatsink have?

It has a black anodized finish.

How can I get technical help for Aavid standard products?

Call (603) 224‑9988 or email [email protected].
