This manual covers the features and specifications of the SOYO SY-A8N4E-RL motherboard, including supported CPUs, memory types, BIOS options, and expansion interfaces. It also includes safety notices and regulatory compliance information.
Detailed installation procedures are provided for the CPU, memory modules, PCI‑Express cards, IDE devices, and RAID configuration, along with diagrams and step‑by‑step guidance to help users set up the board correctly. This manual is written in Chinese.
| CPU socket | AM Socket 754 (Athlon) |
|---|---|
| Memory module type | 184‑pin DIMM |
| SATA ports | 4 SATA 1.5 Gb/s interfaces |
| Floppy connector | 1 floppy drive connector |
| Serial ports | 3 serial ports |
It supports an AM Socket 754 for Athlon processors.
The board provides four SATA 1.5 Gb/s ports.
Yes, it supports RAID modes such as RAID 0 and RAID 1.
