This document is about the specification of S53305-24.000-X clock oscillator product, including the product frequency, temperature range, supply voltage, supply current, output voltage, output load, etc.
The AKER 5 × 3.2 mm SMD Clock Oscillator is a surface‑mount device delivering a nominal frequency of 12 MHz. It is supplied in a compact ceramic package with a metal cap, suitable for high‑density PCB designs.
The device meets RoHS compliance, operates from a 3.3 V supply, and draws up to 7 mA. Electrical characteristics include 50 ppm temperature stability, ±3 ppm/yr aging, and a 10 ns maximum rise/fall time. Mechanical data list a 5.20 mm maximum metal cap height and a recommended 2.54 mm land pattern.
| Nominal Frequency | 12.000 MHz |
|---|---|
| Aging per Year | +3 |
| Operating Temperature Range (Extended) | -40 to +85 °C |
| Storage Temperature Range | -55 to +125 °C |
| Supply Voltage | 3.3 V |
| Supply Current | 7 mA Max |
| Logic High Output Voltage | 90% Vde Min |
| Logic Low Output Voltage | 10% Vde Max |
| Output Symmetry | 40 to 60 % |
| Output Load | 15 pF HCMOS |
| Rise and Fall Time | 10 ns Max |
| Enable‑Disable Function | Tri‑State |
| Package Height (Metal Cap) | 5.20 mm Max |
| Recommended Land Pitch | 2.54 mm |
The oscillator operates at a nominal frequency of 12.000 MHz.
It can operate from –40 °C to +85 °C (extended range).
The device requires a 3.3 V supply and draws up to 7 mA.
Yes, the document states it is RoHS compliant.
