The MAX9505 is a low-power integrated audio/video decoder that filters and amplifies standard-definition video signals.
The MAX9505 video amplifier from Maxim uses DirectDrive™ technology to eliminate large output‑coupling capacitors and set the video black level to ground. It integrates a six‑pole Butterworth reconstruction filter, a 1.7 Ω analog switch, and a charge‑pump with linear regulator to generate a clean negative supply for sync signals.
The device is offered in compact 16‑pin QSOP and 16‑pin TQFN packages and operates over an extended temperature range of –40 °C to +85 °C, making it suitable for space‑constrained, low‑power audio/video portable devices such as mobile phones and handheld video equipment.
| Operating Temperature Range | -40 °C to +85 °C |
|---|---|
| Gain | 6 dB |
| Package Types | 16‑pin QSOP, 16‑pin TQFN |
It is specified for operation from –40 °C to +85 °C.
The part is offered in 16‑pin QSOP and 16‑pin TQFN packages.
