This data sheet provides detailed information about the PIC18F6310/6410/8310/8410 devices, including features, pin configuration, packaging, device dimensions, and performance specifications.
The PIC18F6310/6410/8310/8410 family are 8‑bit flash microcontrollers with nanoWatt technology, offering a wide range of operating modes, flexible oscillator options, and extensive peripheral sets. They support up to 2 Mbytes of external memory (PIC18F8310/8410 only) and include hardware multipliers, multiple timers, and advanced communication modules.
The datasheet provides detailed electrical characteristics, pin diagrams for 64‑pin and 80‑pin TQFP packages, temperature and voltage specifications, and guidance for migration from earlier device families. It also lists contact information for Microchip worldwide support.
| Pin count | 64/80‑Pin |
|---|---|
| Operating voltage range | 2.0 V to 5.5 V (LF) / 4.2 V to 5.5 V (standard) |
| Industrial temperature range | -40 °C to +85 °C |
| Extended temperature range | -40 °C to +125 °C |
| Maximum external memory address | Up to 2 Mbytes |
The devices operate from 2.0 V to 5.5 V for the LF versions and from 4.2 V to 5.5 V for the standard versions.
They are rated for -40 °C to +85 °C in industrial grade and -40 °C to +125 °C in extended temperature grade.
The external memory interface on the PIC18F8310/8410 supports up to 2 Mbytes of addressable memory.
