HA-5020 is a wide bandwidth, high slew rate amplifier optimized for video applications and gains between 1 and 10.
The HA-5020 is a wide‑bandwidth, high‑slew‑rate video amplifier optimized for gains between 1 and 10. It uses current‑mode feedback to maintain higher bandwidth than conventional voltage‑feedback amplifiers and includes a disable pin that reduces supply current and places the output in a high‑impedance state.
Typical applications include unity‑gain video buffers, video gain blocks, coaxial cable drivers, waveform‑generator output stages, and radar or imaging systems. Ordering information, package dimensions, and detailed electrical specifications are provided for both PDIP and SOIC versions.
| Unity Gain Bandwidth | 100 MHz |
|---|---|
| Slew Rate | 0.06 V/µs |
| Output Current (min, guaranteed) | +30 mA |
| Low Supply Current (max) | 10 mA |
| Supply Voltage Range | +5 V to +15 V |
| Gain Flatness (to 5 MHz) | 0.04 dB |
The HA-5020 provides a unity gain bandwidth of 100 MHz.
It has a disable function that significantly reduces supply current and forces the output to a true high‑impedance state.
The device operates with a supply voltage from +5 V to +15 V.
