CEC9680 is a navigation phone that combines GSM, GIS, and GPS technologies. It has a seamless design and high-quality materials, with features such as intelligent voice map navigation and location information exchange.
This manual introduces the UniStrong CEC9680 GSM Phone with built‑in GPS, covering battery installation, SIM card handling, keyboard functions, and basic operation steps. It guides users through powering on, adjusting screen contrast and backlight, managing calls, and using navigation features.
Safety precautions, performance specifications, and maintenance advice are provided to ensure reliable use in various environments, including restrictions for medical devices, aircraft, and explosive areas. This manual is written in Chinese.
| Product name | cgc9680 |
|---|---|
| System | cs ao0/pcsl800 |
| Dimensions | 133 × 51 × 24 mm |
| Weight | 170 g |
| Operating temperature | -15 °C ~ 60 °C |
| Standby time (network) | ≈ 200 hours |
| Standby time (GPS on) | ≈ 10 hours |
| Cold start positioning time | ≈ 45 seconds |
| Hot start positioning time | ≈ 15 seconds |
| Positioning accuracy | < 15 m (95 % confidence) |
| Speed accuracy | 0.05 m/s (steady state) |
| Phonebook capacity | 1000 contacts |
| Waypoint storage | 499 waypoints |
| Battery type | Li‑ion 3.7 V 900 mAh |
| Charger input | 100‑240 VAC 50‑60 Hz |
| Charger output | 5 V 1 A |
Standby time is approximately 200 hours under normal network conditions, and about 10 hours when GPS is continuously active.
Press the power key twice on the standby screen to open the backlight menu, then use the power key to select one of three backlight states.
Keep the phone at least 20 cm away from a pacemaker and follow any local restrictions in hospitals or other medical facilities.
