The MAX9140/MAX9141/MAX9142/MAX9144 are high-speed comparators optimized for systems powered from a 3V or 5V supply.
The MAX9140, MAX9141, MAX9142, and MAX9144 are high‑speed, low‑power comparators optimized for 3 V or 5 V single‑supply operation. They feature rail‑to‑rail input ranges, internal hysteresis, and CMOS/TTL‑compatible outputs, making them suitable for portable equipment, line receivers, and threshold detectors.
The datasheet includes absolute maximum ratings, detailed electrical characteristics, typical operating curves, pin descriptions, and package information. Design recommendations such as proper PCB grounding and decoupling are also provided to ensure full performance of these comparators.
| Power Dissipation per Comparator | 0.45 mW (3 V) |
|---|---|
| Supply Current per Comparator | 150 pA |
| Input Offset Voltage | 0.5 mV min, 2 mV typ |
| Input Hysteresis | 1.5 mV |
| Operating Supply Voltage Range | 2.7 V to 5.5 V |
Each comparator dissipates 0.45 mW at 3 V and draws about 150 pA of supply current.
The MAX9140 is offered in 5‑pin SC70 and 5‑pin SOT23 packages.
