The document describes a range of audio and video connectors with many innovative features. Assembling and disassembling is screwless and can be achieved with a few quick turns of the back shell. The connectors feature a single piece latch that is easy to operate and mates smoothly with both lockable and non-latching connectors. The strain relief collet ensures a secure cable grip. The pressed socket contacts 'float' to assist 'wrap-round' contact with the pin, allowing movement between mating connectors. A range of colored plastic coding rings with a single number molded in provides a quick and easy channel identification system. The connectors also have an internal design feature for quick and simple insert assembly. (Note: These connectors are not suitable for mains applications.)
The Deltron range of audio and video connectors provides a screwless, quick‑turn assembly with a single‑piece latch that works with both lockable and non‑latching mating parts. A coloured plastic coding ring system and interchangeable spring‑loaded rings simplify channel identification.
Mechanical properties include a zinc high‑pressure die‑cast housing with satin‑nickel or black‑chrome finish, PVC strain‑relief, and a polycarbonate screw collar. Electrical specifications list a rated voltage of 250 V AC, 16 A per contact, insertion force of 20 N, withdrawal force of 10 N, and a minimum of 5 000 insertion cycles.
| Rated voltage | 250 Volts AC |
|---|---|
| Rated current per contact | 16 Amps |
| Number of contacts | 3 |
| Maximum wire size | 10 AWG (solid) 6.0 mm |
| Insertion force | 20 N |
| Withdrawal force | 10 N |
| Minimum insertion cycles | 5 000 |
| Operating temperature range | -30 °C to +80 °C |
The connectors are rated for 250 V AC.
The connectors are specified for a minimum of 5 000 insertions.
An insertion force of 20 N is required.
Available colours are Black, Brown, Red, Orange, Yellow, Green, Blue, Violet, Grey, and White.
