This audio and video connector incorporates many innovative features, such as quick-release screws, a simple-to-operate single-piece latching mechanism, a cable strain relief collet, and a range of colored plastic coding rings with molded-in numbers for quick and easy channel identification.
The Deltron Nickel Black series offers screw‑less assembly with a single‑piece latch, strain‑relief collet, and colour‑coded plastic rings for easy identification. Both 4‑Way and 5‑Way configurations are available, with options for silver or gold contacts and various housing materials.
The sheet lists mechanical dimensions (68.0 mm min / 71.5 mm max), operating temperature range (‑30 °C to +80 °C), insertion and withdrawal forces (20 N / 10 N), and a minimum of 5 000 insertion cycles. Electrical data include 4 or 5 contacts, rated current of 10 A (or 7.5 A), wire size up to 14 AWG, capacitance of 7 pF, rated voltage of 250 V ac and test voltage of 1500 V ac.
| Dimensions (min / max) | 68.0 mm / 71.5 mm |
|---|---|
| Operating Temperature | -30 °C to +80 °C |
| Rated Current per Contact | 10 A or 7.5 A |
| Maximum Wire Size | 13 AWG or 14 AWG |
| Capacitance Between Contacts | 7 pF |
| Rated Voltage | 250 V ac |
| Test Voltage | 1500 V ac |
The connectors operate from –30 °C up to +80 °C.
Each contact is rated for either 10 A or 7.5 A.
