This is a range of audio and video connectors incorporating many innovative features. Assembly and disassembly is screwless and is achieved by a few turns of the back shell.
The 8000 Series cable plug from Deltron offers a range of audio and video connectors with screw‑less assembly, satin nickel or matt black finishes, and silver or gold plated contacts. The strain‑relief collet provides a positive cable grip, and coloured coding rings allow quick channel identification.
The leaflet lists mechanical properties such as insertion force (20 N), withdrawal force (10 N), and a minimum of 5 000 insertions, as well as electrical specifications including rated current (up to 16 A), voltage rating (250 V ac), and test voltage (1 500 V ac). Part numbers for 3‑, 4‑ and 5‑way configurations are also provided.
| Finish options | satin nickel or matt black |
|---|---|
| Contact plating | silver or gold plated contacts |
| Strain relief | collet ensures positive cable grip |
| Rated current per contact | 16 A, 10 A or 7.5 A |
| Rated wire size | 14 AWG |
| Capacitance between contacts | 4 pF, 7 pF |
| Rated voltage | 250 V ac |
| Test voltage | 1 500 V ac |
| Operating temperature range | -30 °C to +80 °C |
The connectors are offered in satin nickel or matt black finish.
The rated voltage is 250 V ac.
No, these connectors are not suitable for mains applications.
