ASUS PCH-DR Motherboard User Guide

This user guide introduces the features and characteristics of the ASUS PCH-DR motherboard.

Brand: ASUS
Category: Motherboard
Document type: User Manual
Language: English
Pages: 102
File format: PDF
File size: 981 KB
Published: 06 April, 2012
Updated: 01 October, 2023
MD5 checksum: A0F048304A480EA4C8895C073B235DD9
PDF: ASUS PCH-DR Motherboard User Guide PDF

About this manual

This user guide explains how to install, configure, and operate the ASUS PCH-DR motherboard. It covers product features, hardware installation steps, power‑up procedures, BIOS configuration, and reference information.

The manual includes safety warnings, detailed descriptions of connectors, jumpers, and slots, as well as instructions for updating the BIOS and troubleshooting common issues.

What's inside

Product introduction
Hardware information
Powering up
BIOS setup
Safety information
Appendix: Reference information

Specifications

CPU	Intel Xeon
Front Side Bus	533 MB/s
PCI‑X slots	2
Serial ATA ports	2
DIMM slots	4x DIMMs
USB ports	4 USB1.1/2.0 ports

Frequently asked questions

What safety steps should be taken before moving the system?

Disconnect the power cable from the electrical outlet before relocating the system.

How do I update the BIOS on the PCH-DR motherboard?

Use the BIOS setup menu to manage and update the BIOS as described in Chapter 4.

Download PDF (981 KB)
