This document introduces two models of products, C.A880T D3 V16 and C.A780H D3 V16. It includes hardware installation, driver installation instructions, BIOS settings, etc. It also lists the toxic and hazardous substances or elements in the products.
This manual provides an overview of the Colorful C.A880T D3 V16 and C.A780H D3 V16 motherboards, including the contents of the box, hardware installation steps, driver installation instructions, and detailed BIOS configuration options. It also contains safety information, regulatory compliance details, and support contact information.
The document is organized into chapters covering an introduction, hardware installation, driver installation, BIOS settings (standard, advanced, power management, PCI configuration, health monitoring, frequency/voltage control, and password management), and an appendix with BIOS flashing procedures and diagnostic codes. This manual is written in Chinese.
| Form factor | mATX |
|---|---|
| IDE interface | 1 IDE port |
| Audio | 6‑channel high‑definition audio controller |
| Video outputs | DVI, VGA, HDMI |
The board follows the mATX form factor.
