C.H55T V20/C.H55E V20 motherboard user manual, detailed introduction of the installation, driver installation, BIOS settings and other content.
This manual provides step‑by‑step instructions for installing the Colorful C.H55TV20 and C.H55EV20 motherboards, installing drivers, configuring BIOS settings, and troubleshooting common issues. It also lists the accessories included in the box and how to obtain technical support.
The board follows the mATX form factor and uses the Intel H55 chipset. It supports dual‑channel DDR3 1333/1066 memory, offers one PCI‑Express x16 slot, one PCI‑Express x1 slot, two PCI slots, six SATA2 connectors, ten USB 2.0 ports, a 6‑channel audio codec, and an integrated Gigabit Ethernet controller. This manual is written in Chinese.
| Form factor | mATX |
|---|---|
| Chipset | Intel H55 |
| Memory slots | 2 DDR3 slots, dual‑channel, 1333/1066 MHz |
| PCI‑Express slots | 1 × PCI‑Express x16, 1 × PCI‑Express x1 |
| SATA connectors | 6 × SATA2 |
| USB ports | 10 × USB 2.0 |
| Audio | 6‑channel HD audio codec |
| Network | Integrated Gigabit Ethernet (10/100/1000 Mbps) |
