Foxconn 865A05 Motherboard User Manual

Foxconn 865A05-V1.0-CH-111103 is a power supply.

Brand: Foxconn
Category: Motherboard
Document type: User Manual
Language: Chinese
Pages: 81
File format: PDF
File size: 3.3 MB
Published: 05 April, 2012
Updated: 30 September, 2023
MD5 checksum: C5B3C03A92631568FD09BC9033C3FF5B
PDF: Foxconn 865A05 Motherboard User Manual PDF

About this manual

This manual covers the key specifications of the Foxconn 865A05 series ATX motherboard, including CPU support, memory options, I/O interfaces, and expansion slots. It also provides detailed installation instructions for the CPU, memory modules, and other components.

Additional sections describe BIOS features, power management, and troubleshooting guidance, helping users configure the board for Windows 98/2000/ME/XP and optimize performance with supported hardware. This manual is written in Chinese.

What's inside

Key Features
Physical Dimensions
CPU Support
Memory
USB and IDE Interfaces
Onboard I/O
Graphics
Expansion Slots
Installation Procedures
BIOS and Advanced Features

Specifications

CPU socket	Socket 478
Memory slots	2 DIMM slots
Supported memory types	DDR 266 / DDR 333 / DDR 400
USB ports	6 ports (1 BHCT controller + 4 CHCT controllers)
USB speed	USB 2.0, 480 Mbps
LAN	10/100 Mbit/s
Expansion slots	3 PCI slots, 1 AGP slot
BIOS	Award (Phoenix) BIOS with Flash RAM

Frequently asked questions

What CPU socket does the Foxconn 865A05 motherboard use?

It uses a Socket 478 processor socket.

How many memory slots are available on the board?

The board provides two DIMM slots for DDR memory.

Which USB version is supported and at what speed?

USB 2.0 is supported with a transfer rate of up to 480 Mbps.
