This manual introduces the features and characteristics of the TForce 570 UUUU motherboard, including preface, accessories, motherboard features, etc.
This manual begins with safety instructions and preparation tips for installing the TForce 570 U motherboard, including anti‑static handling, workspace setup, and connector checks. It then details the board layout, rear panel connectors, and the required accessories such as SATA cables and driver CD.
Subsequent sections cover CPU installation, BIOS and CMOS settings, memory testing, RAID configuration, over‑clocking guidance, and a FAQ section. The document also lists technical specifications of the board, including supported processors, memory types, expansion slots, and I/O interfaces. This manual is written in Chinese.
| CPU Socket | AM2 |
|---|---|
| Chipset | mnForce 570 Ultra |
| Form Factor | ATX, 244 mm × 305 mm |
| Network Interface | RJ45 Ethernet |
Use the CMOS clear jumper on the board to reset the CMOS data.
Run the built‑in memory test from the BIOS; enable the test option and start the test without needing additional drivers.
