This manual covers the installation and configuration of the TForce 550 ATX motherboard. It includes safety precautions, a package checklist, and detailed descriptions of the board layout and connectors. The document also provides step‑by‑step hardware installation, jumper and BIOS setup, RAID functionality, driver installation notes, and troubleshooting tips for end users and technicians.
| CPU Socket | AM2 |
|---|---|
| Chipset | nForce 550 |
| DIMM Slots | 4 |
| SATA Transfer Rate | 3 Gb/s |
| LAN | 10/100/1000 Mb/s |
| Form Factor | ATX 219 x 304 mm |
It uses an AM2 socket.
The board has four DDR2 DIMM slots and supports up to 4 GB of total memory.
