This manual provides step‑by‑step instructions for installing the Sakura dish dryer and sterilizer, including mounting position, securing the unit, and completing the electrical wiring and grounding work. It also outlines safety checks such as plane‑level verification and over‑current protection.
Operating instructions cover door opening and closing, shelf installation, and setting the sterilization timer. The specification section lists dimensions, weight, power requirements and protection features for both model Q‑7562S and Q‑7560W. This manual is written in Chinese.
| Dimensions | 800 × 332 × 400 mm (Q‑7562S) / 600 × 332 × 400 mm (Q‑7560W) |
|---|---|
| Net Weight | 17 kg (Q‑7562S) / 10 kg (Q‑7560W) |
| Inner cavity material | Stainless steel |
| Utensil rack material | Stainless steel |
| Overheat protection temperature | 80 °C |
| Heating power | 9 W |
| Operating voltage | 220 V |
| Maximum output power | 270 W |
Use a grounding rod with a resistance of less than 10 Ω, connect the grounding wire to the unit’s grounding terminal, and avoid tying the grounding line to other circuits such as telephone or lightning protection lines.
