About this manual

This document describes the TDA 2140 monolithic integrated circuit used for regenerating and processing the subcarrier reference signals in PAL colour TV receivers. It includes the main features, absolute maximum ratings, mechanical dimensions, and a block diagram of the circuit.

Detailed pin‑by‑pin information, electrical characteristics, and application notes are provided, covering supply voltage, current consumption, output waveforms, colour‑killer operation, and the automatic phase‑control circuit.

What's inside

  • Linear Integrated Circuit Overview
  • Absolute Maximum Ratings
  • Mechanical Data
  • Connection and Block Diagrams
  • Electrical Characteristics
  • Application Information
  • Thermal Data

Specifications

Supply current (pin 2)45 mA – 64 mA
Output voltage V1 (B‑Y) peak‑to‑peak0.9 Vpp

Frequently asked questions

What does pin 9 do?

Pin 9 is the colour‑killer output, which is activated when the antenna signal is too low or the oscillator is not locked.

How is the sandcastle pulse generated?

The sandcastle pulse is taken from the flyback pulse applied at pin 15 and shaped by the RC network connected to pin 14.

What is the maximum flyback pulse amplitude allowed?

The flyback pulse must be negative with a maximum amplitude of 55 Vpp.
