This manual describes the SV301 wireless camera system, including its components, connections, and safety precautions. It guides users through proper installation and operation of the receiver, antenna, and camera.
Key sections cover channel selection for both camera and receiver, usage diagrams of the device, and detailed technical specifications such as frequency, power supply, and environmental limits. This manual is written in Chinese.
| Operating Frequency | 34 GHz |
|---|---|
| Power Supply | DC 3.75 V, 20 mA |
| Power Adapter Input | 100‑240 V AC, 50‑60 Hz |
| Operating Temperature | -16°C to +60°C |
| Operating Humidity | 5% RH |
Use the channel selection diagram in the manual and choose the desired channel (CH1‑CH8) for the camera.
The SV301 requires a DC power supply of 3.75 V at 20 mA.
The device can operate between –16 °C and +60 °C.
